| Design |
| Certification | FCC Part 15 Class B ICES=–3, Issue 4 VCCI V3 (2010.04) Class B KN22 ClassB, KN24 EN55022:2006+A12007 class B EN55024:1998+A1:2011+A2; EN61000-3-2:2006, EN61000-3-3:2008 EN55022:2006 + A1:2007 Class B UL/cUL CE EN 60590 |
| Chipset | Broadcom BCM5719 |
| Internal | Yes |
| Product colour | Green, Grey |
| Legal Information |
| EU ECCN Code | N/A |
| UNSPSC Code | 43201404 |
| US ECCN Code | 5A991 |
| Logistics data |
| Harmonized System (HS) code | 85176990 |
| Network |
| Bandwidth | 8 Gbit/s |
| Cabling technology | 10/100/1000BaseT(X) |
| Ethernet LAN | Yes |
| Ethernet LAN data rates | 10, 100, 1000 |
| Full duplex | Yes |
| Jumbo frames support | Yes |
| Maximum data transfer rate | 2000 Mbit/s |
| Maximum operating distance | 100 m |
| Networking standards | IEEE 802.1Q, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x |
| Wi-Fi | No |
| Operational conditions |
| Operating relative humidity (H-H) | 10 – 90 % |
| Operating temperature (T-T) | |
| |
| |
|
| |
| |
| |
| |
| |
|
| |
|
| |
| |
| |
| |
| |
|
| |
|
| |
| |
| |
| |
|
| |
| |
